Commercial & Residential Ground Mount Options
1-in-Portrait
The 1-in portrait system maximises limited space with a lower profile, available in single or twin post, ideal for height-restricted areas. Its streamlined, vertical arrangement enhances aesthetics and efficiency on narrow plots, reducing installation costs with its simpler configuration.
The Solution for Seamless Commercial & Residential Solar Energy
This innovative system simplifies the complexities of installing ground mounted solar panels, providing a robust and flexible solution for small to medium-scale projects.
Streamlined Design and Installation
Our commercial & residential mounting system is renowned for its intelligent design that streamlines the entire process from site planning to deployment, making it a preferred choice for those seeking efficient solar mounting solutions. By reducing component variations and employing universal parts, not only does it speed up the installation process but also ensures easy system expansion with a single fixing size used throughout.
Rapid Delivery and Unmatched Support
Manufactured in state-of-the-art facilities, our Commercial and Residential mounting system is readily available for prompt delivery, ensuring swift project initiation. At Solarport, we pride ourselves on providing extensive support throughout your project, offering everything from installation training to technical guidance over the phone.
Optimising Each Installation to Specific Site Needs
Engineered to be versatile, our system supports a wide array of solar panel sizes and is compatible with almost any terrain, making it a flexible option for a variety of solar ground mount projects. Whether you’re dealing with commercial or residential settings, it integrates seamlessly with any of our foundation options, optimising each installation to specific site conditions.
Flexible Panel Configuration
Our system is available in multiple configurations, such as 1-in-Portrait, Single and Twin Post, and 2-in-Portrait, with three tilt angle options to enhance solar capture. Each mounting system complies with international quality standards and is adaptable to various ground conditions, making it a comprehensive solution for your solar energy needs.
Cost-Effective & Risk-Reducing Features
Our mounting system is designed to reduce errors and maximise productivity, cutting down on the time and resources needed on-site. These features help decrease labour costs and enhance overall efficiency. Safety is also a priority, with the design minimising common installation risks and promoting safer work environments.
Diverse Foundation Options
Our broad selection of foundation options ensures that systems can be installed on virtually any terrain. From ground anchors in challenging conditions to ballasted systems where minimal ground disturbance is necessary, our mounting system provides stable and durable foundations for every solar project.
Technical Data
Our commercial and residential system is held in stock for rapid distribution and can utilise 6 different foundation options, ensuring that almost no terrain is off limits. The modular design allows for the tables to be built in bays of 2 or 3 panels wide and is suitable for ground up to a maximum slope of approximately 5°.
S450 grade steel. Coating ZM310 & ZM800
Panel configuration:
Panel min and max length:
1-in-Portrait, Single Post
Minimum length: 1650 mm. Maximum length: 2470 mm
Purlin configuration:
2 purlins, position determined by panel dimensions and clamping zones
Panel clamping zones:
Please refer to the panel manufacturer’s specification
Panel clamp specifications:
System angles:
Panels fitted using aluminium top hat and end clamps, with sliding clamps to give mounting positions
20°, 25°, 30°
System min and max heights:
20°: Minimum (clearance): 744 mm, Maximum (to top of rafter): 1332 mm
25°: Minimum (clearance): 759 mm, Maximum (to top of rafter): 1455 mm
30°: Minimum (clearance): 773 mm, Maximum (to top of rafter): 1572 mm
Table configuration min and max:
2 panels x 1 panels min. 30 panels x 1 panels max.
Bay pitches:
2000mm, 2500mm, 3000mm, 3500mm. Each pitch can have 100mm added if an Extension Joiner is used
Foundation types:
C Pile, Concreted Pile,
Material specification:
Wind speed:
Fundamental basic wind velocity within the UK & Ireland up to 26m/s
If your site exceeds this please enquire directly
Snow loads:
0.7 kN/m² max
Design codes:
Designed in accordance with BS EN 1991-1-4:2005 + A1:2010, BS EN 1090 & BS EN 1991 Parts 1, 3 & 7 (Eurocodes)
Commercial & Residential Foundation Options
Whatever the terrain or ground conditions, our range of foundation options have been designed to work on even the most challenging of sites. Our aim is to make sure that, when using a Solarport system, there is no site that's off-limits. We will work with you to ensure the correct foundations are paired to your system and site location, maximising site viability and yield.
